Typical Applications: Fuel Oils (Bunker C and Number 6)
Recommended Materials
Typical Applications: Fuel Oils (Number 4&5)
Typical Applications: Heat Transfer Oils ● Liquid Paraffin
Typical Applications: Lightweight Oils ● Heat Transfer Oils ● Degreasing Solutions
Typical Applications: Forced Air ● Caustic Solutions ● Degreasing Solutions
Typical Applications: Process Water
Typical Applications: Deionized Water
Typical Applications: Clean Water
Typical Applications: Deionized Water
Nickel 18-20%, Chromium 18-22%, Iron balance.
Has about 10% less nickel than Incoloy 800. Used in many air heating applications, where it has exhibited superior oxidation resistance at less cost than Incoloy 800.
Nickel 30-35%, Chromium 19-23%, Iron balance.
The high nickel content of this alloy contributes to its resistance to scaling and corrosion. Used in air heating and immersion heating of potable water and other liquids.
Chromium 16-18%, Nickel 11-14%, Iron balance. (316L - Low Carbon)
Modified with the addition of Molybdenum (2-3%) to improve corrosion resistance in certain environments, especially those which would tend to cause pitting due to the presence of chlorides. Applications include deionized water.
Maximum Sheath Temperature: 1200°F / 649°C
Chromium 18-20%, Nickel 8-11%, Iron balance. (304L - Low Carbon)
Used in the food industry, medical, and chemical heating.
Maximum Sheath Temperature: 1200°F (649°C)
Chromium 17-20%, Nickel 9-13%, Iron balance.
Modified with the addition of Titanium to prevent carbide precipitation and resulting intergranular corrosion that can take place in certain mediums when operating in the 800-1200°F (427-649°C) temperature range.
Standard Copper Alloy
A low temperature, inexpensive material used mainly for clean water heating.
Maximum Sheath Temperature: 350°F / 177°C
Low Carbon
Used for high to low viscosity oils, asphalt, tar, wax, molten salt, heat transfer liquid media and other compatible solutions.
Nickel 38-46%, Chromium 19.5-23.5%, Molybdenum 2.5-3.5%, Iron balance
Available for a limited number of diameters. Consult Tempco for more information.
If your filter selections do not return your desired results from our standard configurations, please continue to select your Specifications.
When you are finished, save your selections in the Wish List (using the button at the right of this page) and follow the steps to submit them to Tempco.
If your filter selections do not return your desired results from our standard configurations, please continue to Refine Results for your specifications.
When you are finished, save your selections with the Save Results for Quote button (at the right of this page) and choose Request for Quote for further assistance.
The Stuffing Box Assembly is used to seal the thermostat capillary when the sensing bulb (3/8" max. OD) is immersed directly in a liquid rather than in a thermowell. The Stuffing Box consists of six slotted washers used to compress a graphite packing into a 3/8" NPT male pipe thread fitting. Assembly Instructions Feed sensing bulb through hole in upper and lower fitting. Insert washers and packing into top cavity of lower fitting. Upper fitting then screws into lower fitting, creating the seal. Part Number: TST-109-101
