Thermocouples are offered with the options listed in the form below. Make your selections and Submit to Tempco for a quote request. Part Numbers are assigned at the time an order is placed.
Style B - Plain Ends
Style C - Spade Lugs with BX Connector
Style D - Miniature Plug
Style E - Miniature Jack
Style J - Standard Jack
Style P - Standard Plug
Style S - Spade Lugs
Calibration Code -- Select --ANSI Standard Tolerances: JANSI Standard Tolerances: KANSI Standard Tolerances: EANSI Standard Tolerances: TANSI Standard Tolerances: NANSI Standard Tolerances: RANSI Standard Tolerances: SANSI Standard Tolerances: BSpecial Tolerances: 3Special Tolerances: 4Special Tolerances: 5Special Tolerances: 6Special Tolerances: 7
Number Of Conductors --Select--2 = Single (Standard)4 = Duplex
Insulation --Select--M = 96% min. MgO (Standard)H = 99.4% min. MgO
Sheath Material --Select--A = Alloy 600B = 304 SSC = 316 SS
Sheath Diameter --Select--A = .020" ±.001B = .032" ±.001C = .040" ±.001D = .063" ±.001E = .093" ±.002F = .125" ±.002G = .188" ±.002H = .250" +.003/−.002J = .313" +.003/−.002K = .375" +.003/−.002L = 1.0mm ±.03N = 1.5mm ±.03P = 2.0 mm ±.03Q = 3.0 mm ±.03R = 4.5 mm ±.05S = 6.0 mm +.07/−.05T = 8.0 mm +.07/−.05V = 9.0 mm +.07/−.05
Sheath Length "L" – Whole Inches 01 to 99
Sheath Length "L" – Fractional Inches --Select--0 = 0"1 = 1/8"2 = 1/4"3 = 3/8"4 = 1/2"5 = 5/8"6 = 3/4"7 = 7/8"
Junction --Select--G = Single GroundedU = Single UngroundedE = Single Exposed4 = Dual, Common Grounded5 = Dual, Common Ungrounded6 = Dual, Common Exposed— = Dual, Isolated Grounded7 = Dual, Isolated Ungrounded8 = Dual, Isolated Exposed
Lead Wire Length – In Inches 001 to 999
Lead Wire Construction --Select--S = Fiberglass 900°F (482°C)B = Fiberglass 900°F (482°C) w/ SS OverbraidA= Fiberglass 900°F (482°C) w/ Flex ArmorT = Teflon 400°F (204°C)D = Teflon 400°F (204°C) w/ SS OverbraidF = Teflon 400°F (204°C) w/ Flex Armor
Lead Wire Termination --Select--P = Standard Male PlugJ = Standard Female JackK = Std. Plug with Mating Conn.D = Miniature Male PlugE = Miniature Female JackF = Miniature Plug with Mating JackB = Standard—2-1/2 in. Split LeadsS = 2-1/2 in. Split Leads with Spade LugsC = 2-1/2 in. Split Leads with BX connector and Spade LugsX = Other (Specify)
Strain Relief Spring --Select--O = Not RequiredY = Required
Optional Compression Fitting --Select--1 = 1/8" NPT SS2 = 1/4" NPT SS3 = 1/2" NPT SS0 = None Required4 = 1/8" NPT Brass5 = 1/4" NPT Brass6 = 1/2" NPT Brass
Special Requirements --Select--H = High temp potting 1000°F (538°C)O = Standard Epoxy Potting 450°F (232°C)X = Other (Specify)
Quantity
Comments
